2024 Yamaha-Ebike Wabash RT

The world might not revolve around us, but it can revolve under us.

Starting at $4,199

SHIMANO GRX

Dedicated design for gravel riding with anti-slip brake levers and a rear derailleur originally introduced for aggressive MTB which reduces chain slap, improves chain retention and minimizes the risk of hitting rocks over rough terrain.

SUGGESTED USE Gravel, Road, Adventure
COLORS Blue Steel
SIZE 54cm (S), 57cm (M), 60cm (L)
MSRP $4,199
TOTAL WEIGHT xx.xlbs (L)
MOTOR Yamaha PWSeries
ST 3-bolt Mount
Square Taper Spindle
Quad Sensor System with rear hub speed sensor
Weight: 7.71lb
Rated power: 250W (Nominal), 500W (Max.)
Max. torque: 70Nm
Max. cadence support: xxxrpm
Max. speed support: 28mph
Support modes: AUTO, ECO+, ECO, STANDARD, HIGH
CONTROL SWITCH AND MULTI-FUNCTION COMPUTER Computer control functions include: (4) Power-level control switch, stop watch, distance units, power-level LED on/off, cycling function display items, time adjustment, LED headlamp power on/off, 3-color LED power assist level light indicator

Cycling function display include: speed, average speed, maximum speed, trip distance, odometer, cadence, battery capacity (%)

BATTERY Yamaha 500Wh with Charge-life indicator and Self-diagnosis display.
Side-exiting dock station with anti-vibration mounting plate
Weight 6.61lb
500Wh 36V
4-hour charge time
FRAME Yamaha Hydroformed Aluminum
Integrated battery
Water bottle boss
Tapered Headtube
Internal shift/brake hose routing
FORK Fork  One-Piece Aluminum
12x100mm Thru-Axle
Fender and rack compatible
Internal brake hose routing
HEADSET Integrated bearing with 30mm of spacers
STEM Yamaha Alloy 4-bolt faceplate
31.8 diameter
80mm length (S)
90mm length (M)
100mm length (L)
HANDLEBAR Flare drop
31.8mm diameter
44cm width
GRIPS/TAPE Padded cork tape
SEATPOST/SADDLE CLAMP Alloy 30.9 x 340mm (S), 395mm (M), 440mm (L) with 2-bolt adjustable tilt saddle rail clamp
SEATPOST COLLAR Alloy 2-bolt 35.0mm
SADDLE Yamaha Off-Road Cro-Mo Rail
SHIFTERS Shimano GRX 11-speed RX600
REAR DERAILLEUR Shimano GRX
CRANKARM Square taper
165mm (S, M)
170mm (L)
CHAIN KMC e11 Turbo EPT
CASSETTE Shimano CS-M7000
11-42t
11-Speed
CHAINRING(S) Shimano GRX 44t
BRAKES/ROTORS Shimano GRX RX600-rear, RX400-front
180mm Centerlock
RIMS 32-Hole Dual Channel Welded Pin w/ Eyeleted Spoke
SPOKES Spokes SUS304
SPOKE NIPPLES SUS304 w/ brass nipple
HUBS Front: 12x100mm TA
Rear: 12x142mm TA with integrated speed sensor
TIRES/TUBES Maxxis Rambler 700 x 45c TR EXO 120tpi
ACCESSORIES Yamaha keys
Yamaha battery charger
Bell
WARRANTY 5-Year on Frame, Drive Unit, Battery
